10816 EXTERN_G_NO_MAC_CYCLE EXP, N12 FBFA
- Macro call via G function DOUBLE PowerOn
-
- 50 -1., -1., -1., -1., -1., -1.,
-1., -1....
- - 2/2
Description: G number for calling a macro.
The name of the subprogram is stated in MD10817 $MN_EXTERN_G_NO_MAC_CYCLE_NAME[n].
If the G function specified with MD10816 $MN_EXTERN_G_NO_MAC_CYCLE[n] is programmed in
a part program block, the subprogram defined in MD10817
$MN_EXTERN_M_NO_MAC_CYCLE_NAME[n] is started. All addresses programmed in the block
are written in the corresponding $C_xx variables.
No subprogram call is executed if a subprogram call is already active via an M/G macro
or
an M
replacement. If a standard G function is programmed in this case, this code is
executed. Otherwise, alarm 12470 is issued.
MD10816 $MN_EXTERN_G_NO_MAC_CYCLE[n] is only active in the external language mode G291.
Only a single subprogram call may be included in any one block. This means that only
a single M/G function replacement may be programmed in a block, and no additional
subprogram (M98) or cycle call may be included in the block.
Furthermore, a subprogram return and a part program end are not permitted in the same
block.
Alarm 14016 is issued in case of a conflict.
10817 EXTERN_G_NO_MAC_CYCLE_NAME EXP, N12 FBFA
- Name of subroutine for G function macro call STRING PowerOn
-
- 50 - - - 2/2
Description: Name of the subprogram started by call via the G function defined by MD10816
$MN_EXTERN_G_NO_MAC_CYCLE[n].
10818 EXTERN_INTERRUPT_NUM_ASUP EXP, N12 FBFA
- Interrupt number for ASUB start (M96) BYTE PowerOn
-
- - 1 1 8 1/1
Description: Number of the interrupt input starting an asynchronous subprogram activated in ISO
mode. (M96 <program number>)
10820 EXTERN_INTERRUPT_NUM_RETRAC EXP, N12 FBFA
- Interrupt number for rapid retraction (G10.6) BYTE PowerOn
-
- - 2 1 8 2/2
Description: Number of the interrupt input triggering rapid retraction to the position programmed
with G10.6 in ISO mode.
10880 MM_EXTERN_CNC_SYSTEM N01, N12 FBFA
- Definition of the control system to be adapted DWORD PowerOn
-
808d-me42 - 1 1 1 0/0
808d-me62 - 1 1 1 0/0
808d-te42 - 2 2 2 0/0
808d-te62 - 2 2 2 0/0
Machine data
3.2 General machine data
Parameter Manual
52 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
