The assignment of individual auxiliary functions to specific groups is defined in
channel-specific machine data ( AUXFU_PREDEF_TYPE, AUXFU_PREDEF_EXTENTION,
AUXFU_PREDEF_VALUE, AUXFU_PREDEF_GROUP, AUXFU_ASSIGN_TYPE, AUXFU_ASSIGN_EXTENTION,
AUXFU_ASSIGN_VALUE, AUXFU_ASSIGN_GROUP ).
M0, M1, M2, M17 and M30 are assigned to group 1 by default.
The specification of this group ( 0x81: output duration 1 OB1 pass, output at end of
block ) must not be changed.
All spindle-specific auxiliary functions ( M3, M4, M5, M19, M70 ) are assigned to group
2 by default.
If several auxiliary functions with different output types ( before / during / at end
of motion ) are programmed in one motion block, then the output of the individual
auxiliary functions occurs in accordance with their output types.
All auxiliary functions are output simultaneously in a block without motion.
Default setting:
AUXFU_GROUP_SPEC[0]=81H
AUXFU_GROUP_SPEC[1]=21H
AUXFU_GROUP_SPEC[2]=41H
...
AUXFU_GROUP_SPEC[n]=41H
11160 ACCESS_EXEC_CST N01 -
- Execution right for /_N_CST_DIR BYTE PowerOn
-
- - 7 0 7 2/2
Description: Execution right assigned to the program stored in directory /_N_CST_DIR :
Value 0: Siemens password
Value 1: Machine OEM password
Value 2: Password of setup engineer, service
Value 3: End user password
Value 4: Keyswitch position 3
Value 5: Keyswitch position 2
Value 6: Keyswitch position 1
Value 7: Keyswitch position 0
Machine data can only be written with values 0 and 1, and with the corresponding
password also active.
11161 ACCESS_EXEC_CMA N01 -
- Execution right for /_N_CMA_DIR BYTE PowerOn
-
- - 7 0 7 2/2
Description: Execution right assigned to the programs stored in directory /_N_CMA_DIR :
Value 0: Siemens password
Value 1: Machine OEM password
Value 2: Password of setup engineer, service
Value 3: End user password
Value 4: Keyswitch position 3
Value 5: Keyswitch position 2
Value 6: Keyswitch position 1
Value 7: Keyswitch position 0
Machine data can only be written with values 0 and 1, and with the corresponding
password also active.
Machine data
3.2 General machine data
Parameter Manual
60 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
