Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
107
Machine data
2.3 Channel-specific machine data
Bit 15 = 0:
Active electronic gearboxes remain active at reset/end-of-part-program.
Bit 15 = 1:
Active electronic gearboxes are canceled at reset/end-of-part-program.
Bit 16 = 0:
Initial setting for the master spindle according to MD20090
$MC_SPIND_DEF_MASTER_SPIND.
Bit 16 = 1:
The current setting of the master spindle (SETMS) is retained.
For MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER = 0, this bit also influences the
behavior of bit 6.
Bit 17 = 0:
Initial setting for the master toolholder according to MD20124
$MC_TOOL_MANAGEMENT_TOOLHOLDER.
Bit 17 = 1:
The actual setting of the master toolholder (SETMTH) is kept.
(Bit17 is only relevant for active tool or magazine management MD20124
$MC_TOOL_MANAGEMENT_TOOLHOLDER > 0. Otherwise, the setting is valid for mas-
ter spindle bit 16, for active tool or magazine management. This bit also
influences the behavior of bit6.)
Bit 18 = 0:
Reference axis for G96/G961/G962 acc. to MD 20100: $MC_DIAMETER_AX_DEF.
When using SCC for a dedicated spindle reset, bit 18 = 1 is recommended (see
also MD 20112 $MC_START_MODE_MASK, bit 18).
Bit 18 = 1:
Reference axis for G96/G961/G962 is retained.
Bit 19: Reserved!
Bit 19= 0:
The two adjustable software limit switches are deleted after reset and are no
longer effective.
Bit 19 = 1:
The two adjustable software limit switches remain active after reset.
Corresponds with:
MD20120 $MC_TOOL_RESET_VALUE
MD20130 $MC_CUTTING_EDGE_RESET_VALUE
MD20150 $MC_GCODE_RESET_VALUES
MD20152 $MC_GCODE_RESET_MODE
MD20140 $MC_TRAFO_RESET_VALUE
MD20112 $MC_START_MODE_MASK
MD20121 $MC_TOOL_PRESEL_RESET_VALUE
MD20118 $MC_GEOAX_CHANGE_RESET
