Siemens SINUMERIK 808D ADVANCED User Manual

PLC User Interface
5.7 NCK signals
Parameter Manual
438 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
5.7.3 Signals at fast inputs and outputs
DB2800 Signals at fast inputs and outputs [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Block digital NCK inputs
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1001 Value from PLC for NCK inputs
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1008 Block digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
1009 Overwrite mask for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
1010 Value from PLC for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
1011 Setting mask for NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
DB2800 Signals at fast inputs and outputs [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Block external digital NCK inputs
Input 16 Input 15 Input 14 Input 13 Input 12 Input 11 Input 10 Input 9
1001 Value from PLC for external digit NCK inputs
Input 16 Input 15 Input 14 Input 13 Input 12 Input 11 Input 10 Input 9
1008 Block external digital NCK outputs
Output 16 Output 15 Output 14 Output 13 Output 12 Output 11 Output 10 Output 9
1009 Overwrite mask for external digital NCK outputs
Output 16 Output 15 Output 14 Output 13 Output 12 Output 11 Output 10 Output 9
1010 Value from PLC for external digital NCK outputs
Output 16 Output 15 Output 14 Output 13 Output 12 Output 11 Output 10 Output 9
1011 Setting mask for external NCK outputs
Output 16 Output 15 Output 14 Output 13 Output 12 Output 11 Output 10 Output 9
