Siemens SINUMERIK 808D ADVANCED User Manual

PLC User Interface
5.4 User Alarms
Parameter Manual
428 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
5.4.2 Variables for user alarms
5.4.3 Active alarm response
5.4.4 Alarm acknowledgement
DB1600 Variables for user alarms [r32/w32]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBD1000 Variable for alarm 700000
DBD1004 Variable for alarm 700001
DBD1008 Variable for alarm 700002
……
DBD1500 Variable for alarm 700125
DBD1504 Variable for alarm 700126
DBD1508 Variable for alarm 700127
DB1600 Active alarm response [r]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2000 Acknowledge
POWER ON
Acknowledge
with
DB1600DBX3
000.0
PLC STOP EMERGENCY
STOP
Feedrate
disable all
axes
Read-in
disable
NC start
disable
2001
2002
2003
DB1600 Alarm acknowledgement [r/w]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
3000 Ack
3001
3002
3003
