PLC User Interface
5.6 Auxiliary functions transfer from NC channel
Parameter Manual
434
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
5.6.2 Decoded M signals (M0 to M99)
8 T fct. 1
change
9
10 D fct.
Change
11
12 H fct. 3
change
H fct. 2
change
H fct.
change
13
14
15
16
17
18
19
Note
The signals are output for the duration of a PLC cycle.
DB2500
M functions from NCK channel [r]
1) 2)
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Dynamic M functions
M7 M6 M5 M4 M3 M2 M1 M0
1001 Dynamic M functions
M15 M14 M13 M12 M11 M10 M9 M8
1002 Dynamic M functions
M23 M22 M21 M20 M19 M18 M17 M16
…...
1012 Dynamic M functions
M99 M98 M97 M96
1013
1014
1015
1)
As the PLC user, you must generate basic functions yourself from the dynamic M functions.
2)
The basic program decodes dynamic M functions (M0 to M99).
