4.3.2 Signals from HMI
corresponding to ... DB3300 DBX3.7 (channel status reset)
Note for the reader Function Manual Basic Functions K1
DB1800
DBX0.0
AUTOMATIC mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
AUTOMATIC mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 AUTOMATIC mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.1
MDI mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
MDI mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 MDI mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.2
JOG mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
JOG mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 JOG mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.7
Reset
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
A reset is initiated for the channel period. All of the current programs are
then in the program status "Aborted". All moving axes and spindles are
decelerated to zero speed according to their acceleration ramp without
contour violation. The initial settings are set (e.g. for G functions). The
alarms are cleared if they are not POWER ON alarms.
Signal state 0 or edge
change 1 → 0
Channel status and program execution are not influenced by this signal.
