Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
15
Explanation of machine data and setting data
1.2 Overview of the data
This will reset all passwords to their defaults according to the software release you have
acquired.
Protection level: 7
If you have deleted your password or do not set a password, you only have the access right of
viewing above-mentioned function areas.
1.2 Overview of the data
Machine and setting data (SINUMERIK)
The machine and setting data are divided into the following areas:
Data Identifiers
The identifier specified in the data description is displayed on the HMI user interface;
however, if the data is addressed in the parts program, for example, the identifier of the
relevant data area must precede the data identifier (designator).
Note
Before per
forming a start-up with default data, you must backup your data; otherwise, you
will have your data lost.
Note
The system by default has no password.
Range Designation
from 200 to 1200 Displaying machine data
from 10000 to 18999 General NC machine data
from 19000 to 19999 Reserved
from 20000 to 28999 Channel-specific machine data
from 29000 to 29999 Reserved
from 30000 to 38999 Axis-specific machine data
from 39000 to 39999 Reserved
from 41000 to 41999 General setting data
from 42000 to 42999 Channel-specific setting data
from 43000 to 43999 Axis-specific setting data
Identifier Data area
$MM_ Displaying machine data
$MN_/ $SN_
$MNS_/ $SNS_
General machine/setting data
