Siemens SINUMERIK 808D ADVANCED

PLC User Interface
5.2 MCP
Parameter Manual
424 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
5.2.2 Signals to MCP
DB1100 To MCP [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
MCP
DBB0 LED 8 LED 7 LED 6 LED 5 LED 4 LED 3 LED 2 LED 1
MCP
DBB1 LED 16 LED 15 LED 14 LED 13 LED 12 LED 11 LED 10 LED 9
MCP
DBB2 LED 24 LED 23 LED 22 LED 21 LED 20 LED 19 LED 18 LED 17
MCP
DBB3 LED 32 LED 31 LED 30 LED 29 LED 28 LED 27 LED 26 LED 25
MCP
DBB4 LED 40 LED 39 LED 38 LED 37 LED 36 LED 35 LED 34 LED 33
MCP
DBB5 LED 48 LED 47 LED 46 LED 45 LED 44 LED 43 LED 42 LED 41
MCP
DBB6 LED 56 LED 55 LED 54 LED 53 LED 52 LED 51 LED 50 LED 49
MCP
DBB7 LED 64 LED 63 LED 62 LED 61 LED 60 LED 59 LED 58 LED 57
7 SEG LED1
DBB8
7 SEG LED2
DBB9
7 SEG LED3
DBB10
7 SEG LED4
DBB11
MCP
DBB12 DP 4 DP 3 DP 2 DP 1
