Siemens SINUMERIK 808D ADVANCED User Manual

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
423
PLC User Interface
5.2 MCP
5.2 MCP
5.2.1 Signals from the MCP
DB1000 From the MCP [r]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
MCP
DBB0 M01 PROGRAM
TEST
MDA SINGLE
BLOCK
AUTO REF.
POINT
JOG Hand-wheel
MCP
DBB1 Key 16 Key 15 Key 14 Key 13 Key 12 Key 11 Key 10 ROV
MCP
DBB2 100 (INC) 10 (INC) 1 (INC) Key 21 Key 20 Key 19 Key 18 Key 17
MCP
DBB3 Key 32 Key 31 CYCLE
START
CYCLE
STOP
RESET SPINDLE
RIGHT
SPINDLE
STOP
SPINDLE
LEFT
MCP
DBB4 Key 40 Key 39 Key 38 Key 37 Key 36 RAPID Key 34 Key 33
MCP
DBB5 Key 48 Key 47 Key 46 Key 45 Key 44 Key 43 Key 42 Key 41
MCP
DBB6 Key 56 Key 55 Key 54 Key 53 Key 52 Key 51 Key 50 Key 49
MCP
DBB7 Key 64 Key 63 Key 62 Key 61 Key 60 Key 59 Key 58 Key 57
Feed override value (in Gray code)
DBB8
Feed override value (in Gray code)
DBB9
MCP
DBB10
