Machine data
2.3 Channel-specific machine data
Description: When an external NC programming language is used, the G codes which become
active on runup and reset or at part program end are defined as a function of
MD20110 $MC_RESET_MODE_MASK and at part program start as a function of
MD20112 $MC_START_MODE_MASK.
The following external programming languages are possible:
ISO2 dialect Milling
ISO3 dialect Turning
The G group division that is to be used is stated in the current SINUMERIK
documentation.
The following groups within MD20154 $MC_EXTERN_GCODE_RESET_VALUES can be
written:
ISO2 dialect M:
G group 2: G17/G18/G19
G group 3: G90/G91
G group 5: G94/G95
G group 6: G20/G21
G group 13: G96/G97
G group 14: G54-G59
ISO3 dialect T:
G group 2: G96/G97
G group 3: G90/G91
G group 5: G94/G95
G group 6: G20/G21
G group 16: G17/G18/G19
20154 EXTERN_GCODE_RESET_VALUES C11, C03 -
- Initial setting of G groups in ISO mode BYTE Reset
-
808d-me42 31 1, 1, 1, 2, 1, 1, 1,
3, 4, 1, 1, 2, 2, 1,
3, 2, 1, 0, 1, 1, 1...
0 - 1/1
808d-me62 31 1, 1, 1, 2, 1, 1, 1,
3, 4, 1, 1, 2, 2, 1,
3, 2, 1, 0, 1, 1, 1...
0 - 1/1
808d-te42 31 1, 2, 1, 2, 2, 1, 1,
0...
0 - 1/1
808d-te62 31 1, 2, 1, 2, 2, 1, 1,
0...
0 - 1/1
