Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
123
Machine data
2.3 Channel-specific machine data
Description: In the case of smooth approach and retraction, the point defined with DISCL,
from which, in the case of infeed from the initial plane, traversing is car-
ried out at lower speed (G341) or the point in which the actual approach
movement begins (G 340), must lie between the initial plane and the approach
plane.
If this point lies outside this interval and the deviation is less than or
equal to this machine data, it is assumed that the point lies in the approach
or retraction plane.
If the deviation is greater, then alarm 10741 is output.
Example:
An approach is made from position Z = 20. The SAR plane is at Z = 0. The point
defined by DISCL must therefore lie between these two values. If it lies
between 20.000 and 20.010 or between 0 and -0.010, it is assumed that the
value 20.0 or 0.0 was programmed (under the condition that the MD has the
value 0.010). The alarm is output if the position is greater than 20.010 or
less than -0.010.
Description: If this machine data is TRUE and tool radius compensation active, the transi-
tions at outer corners where polynomes (splines) are involved can be treated
with the intersection mode. If the machine data is FALSE, conic sections
(circles) are always inserted in this case.
If the machine data is FALSE, the response is identical to that of software
releases older than 4.0.
20204 WAB_CLEARANCE_TOLERANCE C06 W1
mm Change of direction with SAR DOUBLE PowerOn
-
- - 0.01, 0.01, 0.01, 0.01,
0.01, 0.01, 0.01...
0.0 - 1/1
20256 CUTCOM_INTERS_POLY_ENABLE C09 W1
- Intersection procedure for polynomials is possible BOOLEAN PowerOn
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE...
0 - 1/1
