Machine data
2.3 Channel-specific machine data
Parameter Manual
132
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
This machine data defines the behavior of the programmable function CPRECON.
0: The CPRECON function is inactive when feedforward control is activated
simultaneously.
1: CPRECON is also active with feedforward control.
2: As 1, but the function is parameterized with MD32415 $MA_EQUIV_CPREC_TIME.
3: As 2, but any contour accuracy programmed with CTOL has priority over
SD42450 $SC_CONTPREC.
The values 0 and 1 are no longer recommended. They only provide compatibility
with older software versions.
Related to:
SD42450 $SC_CONTPREC
SD42460 $SC_MINFEED
MD32415 $MA_EQUIV_CPREC_TIME
20470 CPREC_WITH_FFW EXP, C06, C05 K6
- Programmable contour accuracy BYTE PowerOn
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 3 0/0
808d-me62 - 3 0 3 1/1
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 3 0/0
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 3 0/0
