Machine data
2.3 Channel-specific machine data
Parameter Manual
136
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
1xxx: Optimization for soft and fast traversing in special applications.
Description: Smoothing of the programmed block end points with compressor type COMPCAD.
Value 0: no smoothing. Value 1: maximum smoothing.
Entry for all dynamic G code groups.
Description: Extent to which the programmed block end points are smoothed in the case of
compressor type COMPCAD for non-geometry axes. Value 0: No smoothing. Value
1: Maximum smoothing.
Entry for each dynamic G code group.
Description: This MD is used to determine the settings for spline interpolation. The allo-
cation of the spline segments to the NC blocks can thus be influenced. With
spline interpolation, the spline blocks are combined, if possible, in such a
way, that there are no blocks that are too short and could lead to a reduc-
tion in the possible path velocity.
Bit 0: With BSPLINE, blocks that are too short are avoided.
Bit 1: With BSPLINE/ORICURVE, blocks that are too short are avoided.
Bit 2: With CSPLINE, blocks that are too short are avoided.
20485 COMPRESS_SMOOTH_FACTOR EXP, C05 B1
- Smoothing by compressor DOUBLE NEW CONF
-
808d-me42 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
808d-me62 5 0., 0., 0.0001,
0.0001, 0.0001
0. 1. 1/1
808d-te42 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
808d-te62 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
20487 COMPRESS_SMOOTH_FACTOR_2 EXP, C05 B1
- Smoothing by compressor DOUBLE NEW CONF
-
808d-me42 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
808d-me62 5 0., 0., 0.5, 0.5, 0.5 0. 1. 1/1
808d-te42 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
808d-te62 5 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0....
0. 1. 1/1
20488 SPLINE_MODE EXP B1
- Setting for spline interpolation BYTE NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 7 3/3
