Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
139
Machine data
2.3 Channel-specific machine data
Description: Tolerance factor for G00.
This factor is used to make different settings for the tolerances for pro-
cessing when G00 is active (rapid traverse, infeed motion).
This tolerance factor is relevant for the following control functions:
1. Compressor (COMPCAD, COMPCURV, and COMPON)
2. Smoothing with G64x
3. Smoothing of orientation with OST
4. Smoothing of orientation response with ORISON
This factor can be both greater than 1 and less than 1. However, higher tol-
erance settings are usual for infeed motion.
If the factor is equal to 1, the tolerances applied for G00 motion are the
same as those for non-G00 motion.
Description: The jerk limitation restricts the path acceleration change in SOFT mode. The
path acceleration divided by the jerk limitation value produces a time in
which the acceleration change takes place.
The jerk limitation is activated on the path by the NC command SOFT, and
deactivated by BRISK.
MD irrelevant for:
Error states that lead to a rapid stop. In addition, the limitation is also
inactive for positioning axes.
There is an entry for each dynamic G code group.
20560 G0_TOLERANCE_FACTOR EXP B1
- Tolerance factor for G00 DOUBLE NEW CONF
-
808d-me42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1
808d-me62 - 3.0 1.e-9 - 1/1
808d-te42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1
808d-te62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1
20600 MAX_PATH_JERK C05 B1,B2
m/s³ Path-related maximum jerk DOUBLE NEW CONF
-
808d-me42 5 1.e6, 1.e6, 1.e6,
1.e6, 1.e6
1.e-9 - 0/0
808d-me62 5 10000., 10000.,
10000., 10000....
1.e-9 - 1/1
808d-te42 5 1.e6, 1.e6, 1.e6,
1.e6, 1.e6
1.e-9 - 0/0
808d-te62 5 10000., 10000.,
10000., 10000....
1.e-9 - 1/1
