Machine data
2.4 Axis-specific machine data
Parameter Manual
250
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
For incremental measuring systems:
The axis travels at this velocity between the time of synchronization with
the first zero mark and arrival at the reference point.
For linear measuring systems with distance-coded reference marks:
The axis travels at this velocity between the time of synchronization (cross-
ing two zero marks) and arrival at the target point.
Description: 1. Standard measuring system (incremental with equidistant zero marks)
Reference point positioning movement: 3rd phase of the reference point
approach:
The axis traverses from the position at which the zero mark is detected with
the velocity REFP_AX_VELO_POS along the path REFP_MOVE_DIST +
REFP_MOVE_DIST_CORR (relative to the marker).
REFP_SET_POS is set as the current axis position at the target point.
2. Irrelevant for distance-coded measuring system.
Override switch and selection jog/continuous mode ( MD JOG_INC_MODE_IS_CONT
) are active.
34070 REFP_VELO_POS A03, A11, A04 G1,R1
mm/min, rev/
min
Reference point positioning velocity DOUBLE Reset
-
808d-me42 - 10000., 10000.,
10000., 720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 10000., 10000.,
10000., 720., 720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 10000., 10000.,
10000., 720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 10000., 10000.,
10000., 720., 720....
(0./ 0.) (1.e300/ 1.e300) 2/2
34080 REFP_MOVE_DIST A03, A11 G1,R1,S1,S3,G2
mm, degrees Reference point distance DOUBLE NEW CONF
-
- 1 -2.0, -2.0 -1e15 1e15 2/2
