Machine data
2.4 Axis-specific machine data
Parameter Manual
266
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
-
The 2nd gear stage data block for tapping with G331/G332 is activated with MD
35010:$MA_GEAR_STEP_CHANGE_ENABLE bit 5 for the master spindle.
Related to:
MD35122 $MA_GEAR_STEP_MIN_VELO2 (minimum speed for 2nd data block gear stage
selection)
MD35092 $MA_NUM_GEAR_STEPS2 (number of gear stages 2nd gear stage data block)
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stage change, 2nd data block is
possible)
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (maximum speed of gear stage with speed
control)
MD35135 $MA_GEAR_STEP_PC_MAX_VELO_LIMIT (maximum speed of gear stage with
position control)
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT (min. speed of gear stage)
Description: -
See MD35120 $MA_GEAR_STEP_MAX_VELO for more information.
Note:
• Programming a spindle speed which undershoots the lowest speed of the
first gear stage MD35120 $MA_GEAR_STEP_MIN_VELO[1] triggers a switch to
the first gear stage.
Not relevant for:
• Programming of speed 0 (S0) if MD35120 $MA_GEAR_STEP_MIN_VELO[1] > 0
Related to:
MD35110 $MA_GEAR_STEP_MAX_VELO (maximum speed for automatic gear stage selec-
tion M40)
MD35090 $MA_NUM_GEAR_STEPS (number of gear stages)
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stage change is possible)
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (maximum speed of the gear stage with
speed control)
MD35135 $MA_GEAR_STEP_PC_MAX_VELO_LIMIT (maximum speed of the gear stage with
position control)
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT (min. speed of the gear stage)
35112 GEAR_STEP_MAX_VELO2 A06, A11, A04 S1
rev/min 2nd data set: Maximum speed for gear stage change DOUBLE NEW CONF
CTEQ
- 6 500., 500., 1000.,
2000., 4000., 8000.
0.0 - 1/1
35120 GEAR_STEP_MIN_VELO A06, A11, A04 S1
rev/min Minimum speed for gear stage change DOUBLE NEW CONF
CTEQ
- 6 50., 50., 400., 800.,
1500., 3000.
0.0 - 2/2
