Machine data
2.2 General machine data
Parameter Manual
30
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Corresponds with....
MD20060 $MC_AXCONF_GEOAX_NAME_TAB (geometry axis name in the channel [GEOAx-
isno.]
MD20080 $MC_AXCONF_CHANAX_NAME_TAB (channel axis name in the channel [Chan-
nelaxisno.]
Description: The position-control cycle is stated as a multiple of the time units of the
system basic cycle MD10050 $MN_SYSCLOCK_CYCLE_TIME.
For PROFIBUS/PROFINET:
In the case of systems with a PROFIBUS DP connection, this MD represents the
ratio between the PROFIBUS DP cycle and the position controller cycle, which
is based on the PLC configuration.
Description: Division ratio between IPO and PLC tasks.
A value of 2 means, e. g. that the PLC task is only processed in every second
IPO cycle. The PLC cycle time is then 2 IPO cycle times. This makes more run-
time available for the other tasks.
The PLC run time must not exceed this PLC cycle time, otherwise an alarm with
PLC STOP is triggered.
Description: Display of the PLC cycle time (not modifiable, is internally generated)
Description: File name with path name under which the list of mounted drives is stored.
10060 POSCTRL_SYSCLOCK_TIME_RATIO N01, N05 G3
- Factor for position control cycle DWORD PowerOn
SFCO
808d-me42 - 2 1 31 7/2
808d-me62 - 1 1 31 7/2
808d-te42 - 2 1 31 7/2
808d-te62 - 1 1 31 7/2
10074 PLC_IPO_TIME_RATIO N01, N05 -
- Factor of PLC task for the main run. DWORD PowerOn
-
-- 1 1 50 2/2
10075 PLC_CYCLE_TIME N01, N05 -
- PLC cycle time DOUBLE PowerOn
-
-- 0.0 - - ReadOnly
10127 EES_MOUNT_FILE EXP -
- Path and name of the file with the mounted drives STRING PowerOn
-
- - /user/sinumerik/mnt/
devices.lst
- - 1/0
