Machine data
2.2 General machine data
Parameter Manual
32
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
This MD defines the number of internal increments per millimeter.
The accuracy of the input of linear positions is limited to the calculation
accuracy by rounding the product of the programmed value and the calculation
accuracy to an integer.
In order to keep the executed rounding easily understandable it is useful to
use powers of 10 for the calculation accuracy.
Description: This MD defines the number of internal increments per degree.
The accuracy of the input of angular positions is limited to the calculation
accuracy by rounding the product of the programmed value and the calculation
accuracy to an integer.
In order to keep the executed rounding easily understandable it is useful to
use powers of 10 for the calculation accuracy.
10200 INT_INCR_PER_MM N01 G2,K3
- Calculation resolution for linear positions DOUBLE PowerOn
LINK
- - 1000. 1.0 1.0e9 2/2
10210 INT_INCR_PER_DEG N01 G2,K3,R2
- Calculation resolution for angular positions DOUBLE PowerOn
LINK
- - 1000.0 1.0 1.0e9 2/2
