Siemens SINUMERIK 808D ADVANCED User Manual

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
323
NC setting data
Description: This setting data writes the taper angle for taper turning. This setting data
is written via the operator interface.
Description: This setting data sets the following during JOG of geometry axes:
Bit 0 = 1 :
A traversing request for the 1st geometry axis is inverted, i.e. a traversing
request to + triggers a traversing motion to - .
Bit 1 = 1 :
A traversing request for the 2nd geometry axis is inverted, i.e. a traversing
request to + triggers a traversing motion to -.
Bit 2 = 1:
A traversing request for the 3rd geometry axis is inverted, i.e. a traversing
request to + triggers a traversing motion to -.
Description: If no axial scaling factor I, J, or K is programmed in the G51 block, SD43120
$SA_DEFAULT_SCALE_FACTOR_AXIS is active. The scaling factor is only active if
MD22914 $MC_AXES_SCALE_ENABLE is set.
Related to:
MD22914 $MC_AXES_SCALE_ENABLE,
MD22910 $MC_WEIGHTING_FACTOR_FOR_SCALE
42995 CONE_ANGLE --
- Taper angle DOUBLE Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... -90 90 7/7
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... -90 90 7/7
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359 7/7
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359 7/7
42996 JOG_GEOAX_MODE_MASK --
- JOG of geometry axis mode DWORD Immediately
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2
43120 DEFAULT_SCALE_FACTOR_AXIS -FBFA
- Axial default scaling factor with G51 active DWORD Immediately
-
-- 1 - - 2/2
