Machine data
2.2 General machine data
Parameter Manual
34
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Bit mask for parameterizing various display variables:
BitNo. Hexadec. Meaning with bit set
value
Bit0: 0x1
Parameters are assigned to the OPI variable lastBlockNoStr in the SPARP and
SPARPP blocks.
Bit1: 0x2
Concerns the OPI variable cmdSpeed in the SPARPP block. If the bit is set,
the variable returns the programmed speed even if the spindle is at a stand-
still or in another mode (positioning mode, axis mode).
Bit2 0x4
Concerns the OPI variable cmdSpeed in the SPARPP block. (reserved for con-
stant cutting speed)
Bit8: 0x100
Servotrace manages larger numerical values internally. Overruns in data for-
mat are avoided. The accuracy may be reduced with large numerical values.
Description: For PROFIBUS/PROFINET:
1st + 2nd byte indicate the logical start address of the I/O slot on the
PROFIBUS/PROFINET:
Value 0000 means NO active slot
Values 0001..0100 are reserved for the PLC process image (the value of input
slots can be read by the NCK without errors; however, output slots are for-
bidden in this range, and cause an alarm on power up)
1st byte = LowByte of the logical start address
2nd byte = HighByte of the logical start address
3rd byte = 0 = without meaning
4th byte = 5 = segment no. for PROFIBUS/PROFINET
The individual bytes are explained under MD10366 $MN_HW_ASSIGN_DIG_FASTIN.
[hw] = Index (0 to 3) for addressing the external digital output bytes
Related to:
MD10366 $MN_HW_ASSIGN_DIG_FASTIN
MD10362 $MN_HW_ASSIGN_ANA_FASTIN
MD10364 $MN_HW_ASSIGN_ANA_FASTOUT
10284 DISPLAY_FUNCTION_MASK EXP, N01 -
- Behavior of various display variables DWORD PowerOn
-
-- 0x0 0 - 1/1
10368 HW_ASSIGN_DIG_FASTOUT N10 A4
- Hardware assignment of external digital NCK outputs DWORD PowerOn
-
- 4 0x01000000,
0x01000000,
0x01000000...
0x01000000 0x060003FF 2/2
