Detailed descriptions of interface signals
4.6 Mode signals
Parameter Manual
348
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Signal state 0 or edge
change 1 → 0
The machine function in question is not selected. No change is requested to
the active machine function.
If an axis is currently traversing an increment, this movement is also aborted
if this machine function is deselected or switched over.
corresponding to ... IS "INC inputs active in the mode area" (DB2600 DBX1.0)
IS "Machine function 1 INC, ..., continuous"
for axis 1 in the Work (DB3200 DBX1001.0 to .6)
for axis 2 in the Work (DB3200 DBX1005.0 to .6)
for axis 3 in the Work (DB3200 DBX1009.0 to .6)
IS "Machine function 1 INC, ..., continuous" in the axis area (DB380x DBX5.0
to .6)
IS "Active machine function 1 INC, ..., continuous"
for axis 1 in the Work (DB3300 DBX1001.0 to .6)
for axis 2 in the Work (DB3300 DBX1005.0 to .6)
for axis 3 in the Work (DB3300 DBX1005.0 to .6)
IS "Active machine function 1 INC, ..., continuous" in the axis area (DB390x
DBX5.0 to .6)
Note for the reader Function Manual Basic Functions H1
DB3100
DBX0.0
Active AUTOMATIC mode
Signal(s) from NCK (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
AUTOMATIC mode is active.
Signal state 0 or edge
change 1 → 0
AUTOMATIC mode is not active.
Note for the reader Function Manual Basic Functions K1
DB3100
DBX0.1
Active MDI mode
Signal(s) from NCK (NCK → PLC)
Edge evaluation: Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
MDI mode is active.
Signal state 0 or edge
change 1 → 0
MDI mode is not active.
Note for the reader Function Manual Basic Functions K1
DB3100
DBX0.2
Active JOG mode
Signal(s) from NCK (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
JOG mode is active.
Signal state 0 or edge
change 1 → 0
JOG mode is not active
Note for the reader Function Manual Basic Functions K1
