Detailed descriptions of interface signals
4.7 Channel-specific signals
Parameter Manual
352
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Application example This allows protection zones to be enabled:
• if the actual position is within a protection zone (alarm 2 present)
• if motion is to be started towards the protection zone limit (alarm 1 or 2
present)
Note for the reader Function Manual Basic Functions K1
DB3200
DBX1.7
Activate the program test
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Axis disable is set internally for all axes (not spindles). Therefore the
machine axes do not move when a part program block or a part program is
being processed. The axis movements are simulated on the operator
interface with changing axis position values. The axis position values for
the display are generated from the calculated setpoints.
Otherwise, the part program is executed normally.
Signal state 0 or edge
change 1 → 0
The part program execution is not affected by the program test function.
corresponding to ... IS "Program test selected"
IS "Program test active"
Note for the reader Function Manual Basic Functions K1
DB3200
DBB2
DBX15.6 and .7
Activate skip block
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Blocks marked in the part program with a slash (/) are skipped. If there is a
series of skip blocks, this signal is only active if it is present before
decoding of the first block of the series, ideally before "NC start".
Signal state 0 or edge
change 1 → 0
The marked part program blocks are not skipped.
corresponding to ... IS "Skip block selected"
Note for the reader Function Manual Basic Functions K1
