Detailed descriptions of interface signals
4.7 Channel-specific signals
Special cases, errors,
...
When the axes have been stopped with IS "Delete distance-to-go" the next
program block is prepared with the new positions. After a "Delete distance-
to-go", geometry axes thus follow a different contour to the one originally
defined in the part program.
If G90 is programmed in the block after "Delete distance-to-go" it is at least
possible to approach the programmed absolute position. On the other hand,
with G91, the position originally defined in the part program is not reached in
the following block.
corresponding to ... DB380x DBX2.2 (Distance-to-go / Spindle reset)
Note for the reader Function Manual Basic Functions K1
DB3200
DBX6.4
Program level abort
Signal(s) to channel (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
At each edge change 0 → 1 the actual program level being processed
(subprogram level) is immediately aborted. Processing of the part program
continues at the next higher program level from the exit point.
Signal state 0 or edge
change 1 → 0
No effect
Special cases, errors,
...
The main program level cannot be interrupted with the IS, but only with the
IS "Reset".
Note for the reader Function Manual Basic Functions K1
DB3200
DBX6.6
Rapid traverse override active
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The rapid traverse override between 0 and a maximum of 100% entered in
the PLC interface is channel-specific.
Signal state 0 or edge
change 1 → 0
The rapid traverse override entered at the PLC interface is ignored.
When the rapid traverse override is inactive, the NC always uses 100% as
the internal override factor.
Note:
The 1st switch position of the gray-coded interface for the value is an
exception. Also here for "Rapid traverse override inactive", this override
factor is used and for axes, 0% is output as override value.
Special cases, errors,
...
The rapid traverse override is inactive when G33 is active.
corresponding to ... IS "Rapid traverse override" (DB3200 DBX5)
Note for the reader Function Manual Basic Functions V1
DB3200
DBX6.7
Feedrate override active
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The feedrate override between 0 and a maximum of 120% entered at the
PLC interface is active for the path feedrate and therefore aut
omatically for
th
e related axes.
In JOG mode, the feedrate override acts directly on the axes.
