Detailed descriptions of interface signals
4.7 Channel-specific signals
Parameter Manual
370
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Signal state 1 The running program has come to a program command WAIT_M or WAIT_E
in an NC block. The wait condition specified in the WAIT command for the
channel or channels has not yet been fulfilled.
Signal state 0 Program status wait is not active.
corresponding to ...
Note for the reader /PG/ Programming Manual, Fundamentals
DB3300
DBX3.2
Program status stopped
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The NC part program has been stopped by an "NC stop", "NC stop axes plus
spindles", "NC stop at the block limit", programmed M0 or M1 or single block
mode.
Signal state 0 Program status "stopped" is not present.
corresponding to ... IS "NC stop"
IS "NC stop axes plus spindles"
IS "NC stop at block limit"
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.3
Program status interrupted
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 When the mode changes from AUTOMATIC or MDI (in stopped program
status) to JOG, the program status changes to "interrupted". The program
can be continued at the point of interruption in AUTOMATIC or MDI mode
when "NC start" is issued.
Signal state 0 Program status interrupted is not active.
Special cases, errors,
...
The IS "Program status interrupted" indicates that the part program can
continue to be processed by restarting it.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.4
Program status aborted
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The program has been selected but not started, or the program was aborted
with a reset.
Signal state 0 Program status interrupted is not active.
corresponding to ... IS "Reset"
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.5
Channel status active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
