Detailed descriptions of interface signals
4.8 Axis / spindle-specific signals
DB390x
DBX2000.0 to .2
Setpoint gear stage A to C
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
A gear stage can be defined as follows:
• Permanently by the part program (M41 to M45)
• Automatically by the programmed spindle speed (M40)
M41 to M45:
• The gear stage can be permanently defined in the part program with
M41 to M45. If a gear stage is specified using M41 to M45, which is not
equal to the actual (actual) gear stage, then the IS "Change gear stage"
and the IS "Setpoint gear stage" A" to "...C" are set.
M40:
• The control automatically defines the gear stage with M40 in the part
program. The control checks which gear stage is possible for the
programmed spindle speed (S function). If a gear stage is selected that
is not the same as the actual (actual) gear stage, then the IS "Change
gear stage" and the IS "Setpoint gear stage" A" to "...C" are set.
The setpoint gear stage is output in coded format:
1. Gear stage
1st gear stage
2nd gear stage
3rd gear stage
4th gear stage
5th gear stage
invalid value
invalid value
0 0 0 (C B A)
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Signal irrelevant for ... Other spindle modes except oscillation mode
corresponding to ... IS "Change gear stage" (DB390x DBX2000.3)
IS "Actual gear stage A" to "...C" (DB380x DBX2000.0 to .2)
IS "Gear stage is changed over" (DB380x DBX2000.3)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX2000.3
Change gear stage
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
