Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
419
Detailed descriptions of interface signals
4.8 Axis / spindle-specific signals
corresponding to ... MD37550 EG_VEL_WARNING
(threshold value, velocity alarm threshold)
MD32000 MAX_AX_VELO (maximum axis velocity)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX5002.6
Acceleration alarm threshold reached
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 When the acceleration of the following axis in the axis grouping of the
electronic gear reaches or exceeds the percentage of the acceleration
entered in MD37550, which is set in MD32300, then the signal is set to 1.
Signal state 0 The acceleration of the following axis in the axis grouping of the electronic
gear falls below the threshold value described above.
corresponding to ... MD37550 EG_VEL_WARNING
(threshold value, velocity alarm threshold)
MD32300 MAX_AX_ACCEL (axis acceleration)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX5003.3
Axis is accelerating
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 When the acceleration of the following axis in the axis grouping of the
electronic gear reaches or exceeds the percentage of the acceleration
entered in MD37560, which is set in MD32300, then the signal is set to 1.
Signal state 0 The acceleration of the following axis in the axis grouping of the electronic
gear falls below the response value described above.
corresponding to ... MD37560 EG_ACC_TOL (threshold value for "accelerate axis")
MD32300 MAX_AX_ACCEL (axis acceleration)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX5008.0 to .5
Active infeed axes
Signal(s) from axis / spindle
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The axis, from which the signal is received is presently the oscillating axis
and in this field, signals its active infeed axes (DBX5008.0 axis 1 is the
infeed axis, DBX5008.1 axis 2 is the infeed axis, etc.)
Signal state 0 The associated axis is not an infeed axis.
corresponding to ... DB390x DBX5004.7 (oscillation active)
Note for the reader Function Manual, Expansion Functions P5
