Machine data
2.2 General machine data
Parameter Manual
42
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
The M functions defined by MD10713 $MN_M_NO_FCT_STOPRE perform an implicit
preprocessing stop.
That is, the interpretation of the next part program line will be stopped
until the block with the M function defined in that way has been processed
completely
(PLC acknowledgement, motion, etc.).
Description: For spindles where a '2' is configured in MD35040
$MA_SPIND_ACTIVE_AFTER_RESET, no spindle reset is enabled with this M func-
tion when the part program is terminated. The spindle therefore remains
active after the end of the part program.
Proposal: M32
Restrictions: see MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT,
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN,
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
MD26008 $MC_NIBBLE_PUNCH_CODE
10713 M_NO_FCT_STOPRE EXP, N12, N07 H2
- M function with preprocessing stop DWORD PowerOn
-
- 15 -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2
10714 M_NO_FCT_EOP EXP, N07 K1,H2
- M function for spindle active after reset DWORD PowerOn
-
- - 32 - - 1/1
