Machine data
2.3 Channel-specific machine data
Description: Definition of the default setting for the master spindle (in the channel).
The number of the spindle is entered.
A number of functions are linked to the master spindle, which are not possi-
ble with any other spindle.
Note:
The language command SETMS(n) can declare the spindle number as the master
spindle.
The spindle defined in this MD is declared once again as the master spindle
with SETMS.
The spindle defined in this MD is also declared as the master spindle at pro-
gram end and program cancelation.
Description: This machine data defines the M auxiliary function number with which the
spindle is switched into axis mode.
The M number defined in the machine data replaces M70 in Siemens language
mode.
Note:
On the VDI interface, M70 is always output with the corresponding address
extension to indicate the switch to axis mode.
Restrictions: Refer to machine data MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT,
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN,
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
$MD26008 $MC_NIBBLE_PUNCH_CODE
20090 SPIND_DEF_MASTER_SPIND C01, C03 H2,K1,K2,P3 pl,P3 sl,S1,W1
- Initial setting of master spindle in channel BYTE PowerOn
-
808d-me42 - 1, 1, 1, 1, 1, 1, 1, 1... 1 1 1/1
808d-me62 - 1, 1, 1, 1, 1, 1, 1, 1... 1 2 1/1
808d-te42 - 1, 1, 1, 1, 1, 1, 1, 1... 1 1 1/1
808d-te62 - 1, 1, 1, 1, 1, 1, 1, 1... 1 2 1/1
20094 SPIND_RIGID_TAPPING_M_NR C01, C03, C10 H2,K1,S1
- M function for switching into controlled axis mode DWORD PowerOn
-
- - 70, 70, 70, 70, 70, 70,
70, 70...
- - 2/2
