Siemens SINUMERIK 840C Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
1–4
SINUMERIK 840C / SIMODRIVE 611–D (DA)
1.3 Display of the alarms in the alarm line
Messages from the monitoring system are displayed in the alarm line. Existing
comments are overwritten by alarm texts. The alarm line is the second display
line from the top.
Machine Parameter Programm. Services Diagnosis
AUTOMATIC
Program stop
M. grp.: 1
Channel: 1
POWER
ON
Actual
values
Distances to
go
Program pointer
%1234
N1234
L1234 N1234P12
X 10.789
Y 5.231
Z 210.643
100.000
10.000
200.000
Alarm line
Delete error condition
There are three types of display representation for alarm messages: Types A, B
and C.
Example of display Alarm display in sequence order
representation Type A:
Machine Parameter Programm. Services Diagnosis
10243 ORD 5 X Illegal pulse multiplication
max. 6 characters for alarm number
max. 5 characters for ordinal number
The ordinal number shows the order
in which the alarms have occurred.
max. 40 characters
for explanatory text
(for single-line alarm)
max. 100 characters
(for two-line alarm)
1 Alarms
1.3 Display of the alarms in the alarm line
