04/96
Siemens AG 2001 All rights reserved 6FC5198–jAB40
2–7
SINUMERIK 840C / SIMODRIVE 611–D (DA)
2.2 Additional error information
(ACCU 3 low byte, DB 1 DW 161–163)
For all errors marked with an *) in the above list, further information is given in the
additional fields. This information can be read out using the programmer from ad-
dresses F0001 to F0004 or from DW161 to 164 in the diagnostics DB (DB1).
In the additional error information marked by ++) the representation of F0001 -
F0004 on the operator panel and in DB1 high/low is swapped.
This information is summarized below:
Error No. Address Contents/Designation
01 F0000
F0001
F0002
F0003
01: Error number incorrect MC5 operation code
OB number where incorrect operation code occurred
––
––
02, 03, 04,
05, 06, 07,
08, 09, 0E,
0F
F0000
F0001
F0001
F0002
F0003
Error number of interpreter
High byte: Identifier for preceding command
Low byte: OB number where the error occurred
Operation code of the MC5 command which led to error
Parameter of MC5 command in BCD code ++)
Identifier for preceding command:
0: No command modification
1: Preceding command was B MW, B DW, B BS or substitution
command
0A F0000
F0001
F0002
F0003
0A: Overflow in interruption stack
OB number where overflow occurred
––
––
0B F0000
F0001
F0002
F0003
0B: Stop caused by STS command
OB number where STS occurred
––
––
0D F0000
F0001
F0002
F0003
0D: Error number processing time delay
OB number where processing time delay occurred
––
––
2 Diagnostics on the PLC
2.2 Additional error information (ACCU 3 low byte, DB 1 DW 161–163)
