PLC machine 7. The machine data test is performed in the code restart branch.
data test
8. If the machine data are invalid, the group error number 110D (6EH) is transfer-
red in the error field (address F0000 with programmer, cell FEHLCOD for sy-
stem program). The detailed error identifiers for each test are entered in the
additional error field (address F0001 with programmer, cell EADOPAD + 1 for
system program).
9. Detailed error identifiers
Address
F0000 F0001
Error
0 Reserved
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 PLC MD for error and operational messages (channel-specific) set
8 PLC MD for error and operational messages (spindle-specific) set
9 PLC MD for error and operational messages (axis-specific) set
10 PLC MD for M decoding with extended addresses set. At least one decoding list is
missing.
11 PLC MD “1st machine control panel” set – input missing
6E
12 PLC MD “2nd machine control panel” set – input missing
13 Reserved
14 Reserved
15 PLC MD “1st machine control panel” set – output missing
16 PLC MD “2nd machine control panel” set – output missing
17 Reserved
18 Reserved
19 PLC MD for error and operational messages (DB58) set
20 Reserved
21 Reserved
22 Reserved
23 Reserved
2 Diagnostics on the PLC
2.2 Additional error information (ACCU 3 low byte, DB 1 DW 161–163)
