04/96
Siemens AG 2001 All rights reserved 6FC5198–jAB40
2–5
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Timeouts
98 Timeout with transfer in/out (see errors B0 and B1)
99 Timeout cannot be interpreted with active interpreter *)
9A Timeout with processing a function macro *)
9B Timeout with processing high-level language blocks *)
9C Timeout with access to pabe
commands LB CB, LB CW, LB CD, TB CB, TB CW, TB CD
Error messages of distributed I/Os
W A0 Transfer error to an expansion unit
W A1 Overtemperature in an expansion unit or bouncing enable input with SIMATIC I/O devices
W A2 Interface DMP outputs a command output disable during operation
W A3 Transmission link to EU 185U (SIMATIC EU) has failed
W AF Message “OUTDS” from power supply unit
W B0 Input module failed or changed and STOP set for PLC for this module via MD *)
W B1 Output module failed or changed and STOP set for PLC for this module via MD *)
Cycle time monitoring
C0 Cycle time exceeded
C1 Cycle time exceeded; FB12 called more than twice per cycle
Error messages when
using the PLM and C
high-level languages
HLL call in the interpreter
D0 Unknown type identifier in parameter declaration of the FB called
D1 Illegal type identifier block
D2 Unknown code in the parameter block of the FB called: input parameter
D3 Unknown code in the parameter block of the FB called: output parameter
HLL_HLL function
D4 Unknown pseudo parameter in STACK
D5 Block not available
D6 HLL block not in line with paragraph
D7 Block called is not a HLL block
HLL_ADB function
D8 DB to be opened in HLL: wrong pseudo parameter
D9 DB to be opened not available
DA DB to be opened not in line with paragraph
2 Diagnostics on the PLC
2.1 Error numbers (ACCU 3 high byte, DB 1 DW 160)
*) Additional information is given on this error in additional fields (see Section 2.2)
