04/96
Siemens AG 2001 All rights reserved 6FC5198–jAB40
2–3
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Cold restart
4B System parameters: Incorrect ms time frame
4C System parameters: Incorrect 10 ms time frame
4D System parameters: Incorrect 100 ms time frame
4E System parameters: Incorrect MC5 time (programmer cannot be used for diagnosis in PLC)
4F Unassigned
51 Impermissible input value for byte number of the alarm byte
51 Byte number for alarm byte assigned more than once
52 Alarm byte number specified but byte does not exist or impermissible machine control panel
53 Irregular block type: PLM block not allowed in user program memory
54 Irregular block type: C block not allowed in user program memory
55 Synchronization error in EPROM basic program memory *)
56 Synchronization error in EPROM user program memory *)
57 Synchronization error in RAM user program memory *)
58 Synchronization error in RAM user data memory *)
59 Irregular block type in EPROM basic program memory *)
5A Irregular block type in EPROM user program memory *)
5B Irregular block type in RAM user program memory *)
5C Irregular block type in RAM user data memory *)
5D Summation error with RAM for OB, FB, DB, FX, SB, PB *)
5E Summation error with EPROM for OB, FB, DB, FX, SB, PB *)
Restart
5F Impermissible warm restart *)
60 Check sum error in RAM for OB, FB, DB, FX, SB, PB *)
61 Check sum error in EPROM for OB, FB, DB, FX, SB, PB *)
Cold restart and/or warm restart
62 No RAM user program memory available
63 No user data memory available
64 Operator panel input byte in impermissible area
65 Operator panel output byte in impermissible area
66 No synchronization pattern from master in cold restart *)
67 No synchronization pattern from master in warm restart *)
68 Process image of the inputs: impermissible value for delete limit
69 Input is in retentive area of the process image
6A Process image of the outputs: impermissible value for delete limit
6B Output is in retentive area of the process image
6C Function URLADE not executed, submodule not inserted or empty
1
)
6D Error during function: Save user program on MMC hard disk
1
)
6E Machine data error equivalent to FB25 on the 850 *) (see special section)
W 6F EUs or DMP modules not switched on or incorrectly jumpered (rotary switch) *)
2 Diagnostics on the PLC
2.1 Error numbers (ACCU 3 high byte, DB 1 DW 160)
*) Additional information is given on this error in additional fields (see Section 2.2)
1) SW 3 and higher
