SINUMERIK 840C / SIMODRIVE 611–D (DA)
4 Errors with Function Macros
ACCU 1
(FB No.)
ACCU 2
(Error
No.)
Error
occurred at
Error description
11
1
2
3
4
5
6
7
8
Setting up data
blocks
DB No. impermissible
DB No. > 255
Specified DW No. < 0
Length of DB to be set up is not the same as the length of
the DB already in the PLC
Memory space in the PLC no longer sufficient
Existing DW No. > 255
DB No. = 0
DB type different from DB or DX
12
1
Retriggering of
cycle time monito-
ring
PLC Stop with error detection 0C1H on 3rd call of FB12
within one PLC cycle
52
1
2
3
4
5
6
7
8
9
Block transfer
Illegal mode
Number of DWs to be transferred > 127
Number of DWs to be transferred < 0
Segment No. of 8-bit memory < 1 or > 13
Segment No. of 16-bit memory < 1 or > 13
Offset of 1st DW in 8-bit memory > 7FFFH
Offset of 1st DW in 16-bit memory > 7FFFH
Selected 8-bit memory area exceeds lower segment limit
(not with segment Nos. 6, 10, 11,12)
Selected 16-bit memory area exceeds lower segment limit
(not with segment Nos. 6, 10, 11,12)
60
1
2
3
4
5
6
7
8
9
Block transfer
Number of DWs to be transferred > 2043
Number of DWs to be transferred = 0
Target DB No. = 0
Target or source DB not available
Target DB too short
Target DB in EPROM
Source DB too short
Incorrect TYQU parameter
Incorrect TYZI parameter
