SINUMERIK 840C / SIMODRIVE 611–D (DA)
Error descriptionError
occurred at
ACCU 2
(Error
No.)
ACCU 1
(FB No.)
61
v0
v1
v2
v3
v4
v5
v6
v7
v8
Read NC data
ANZ > 1 not permitted
NSBY not permitted
DB missing or DB No. not permitted or
MW not permitted
Data type not permitted
*ANZ = 0 or > 128
Reading / writing not permitted
Number format not permitted
Value 3 for ZOA or ZOFA not equal or 1
Type data target/data source in PLC not permitted
62 Write NC data See FB 61 (reading NC data)
65
1
Transfer flags →
flag stacks
Stackpoint overflow
66
1
Transfer flag
stack → flags
Stackpoint not reached
67
2
1
Transfer machine
control panel
signals → DB
axes
Parameter axis No. > 30
PLC machine data not set for signals from/to axis
68
1
Aperiodic user
program call
Parameter tool < 0
69
1
2
3
G decoding
Channel number not permitted
G group incorrect
PLC MD: signals from/to NC channel or signals from NC
channel not set
70
1
2
3
4
5
6
7
Transfer interfa-
ces DB to I/Q/F
Source or target type incorrect (illegal ASCII character)
Source DB does not exist in PLC
Parameter limits of source or target parameter not re-
ached or exceeded
Source or target DB too short
Parameter limit of flag area exceeded
PII or PIQ limits exceeded
Illegal source or target parameter type (not I, Q, F)
4 Errors with Function Macros
