Siemens SINUMERIK 840C Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
4–3
SINUMERIK 840C / SIMODRIVE 611–D (DA)
ACCU 1
(FB No.)
ACCU 2
(Error
No.)
Error occur-
red during
Error description
71 Transfer interface
DB to I/Q/F (see
FB 70)
72
1
Transfer NC
channel to DB
channel-specific
signals
Channel address not permitted
73
1
Transfer DB
channel-specific
signals to NC
channel
Channel address not permitted
74
1
Transfer spindle
to DB spindle-
specific signals
Spindle address not permitted
75
1
Transfer DB
spindle-specific
signals to spindle
Spindle address not permitted
76
1
Transfer axis to
DB axis-specific
signals
Axis address not permitted
77
1
Transfer DB axis-
specific signals to
axis
Axis address not permitted
78
1
2
3
Transfer machine
control panel
signals →
channels/spindles
PLC machine data not set for signals from/to channel
PLC machine data not set for signals from/to spindle
Parameterized channel No. or spindle No. too large
79
1
2
Transfer machine
control panel
signals → DB
axes
PLC machine data not set for signals from/to axis
Number of parameterized axes > 30
88
1
2
Mode lamp
PLC MD signals from/to channel not set
Parameterized channel No. >4
89
1
2
3
Reading of block
start address
Block type not permitted
Address list does not exist
Address list insufficient
113 Symmetrical tool
search
No messages
END OF SECTION
4 Errors with Function Macros
