Siemens SINUMERIK 840C Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
1–5
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Example of display Alarm display in block number order
representation Type B:
Machine Parameter Programm. Services Diagnosis
3000 1 N0045 General programming error
max. 5 characters for alarm number
max. 5 characters for block number
E.g.: the error has occurred in block N0045.
max. 38 characters
for explanatory text
(for single-line alarm)
1 character for channel number
Example of display
representation Type C:
Machine Parameter Programm. Services Diagnosis
6000 Hydraulic oil min.
max. 4 characters for alarm number
max. 47 characters
for explanatory text
(for single-line alarm)
1 Alarms
1.3 Display of the alarms in the alarm line
