04/96
Siemens AG 2001 All rights reserved 6FC5198–jAB40
2–8
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Contents/DesignationAddressError No.
28 F0000
F0001
F0002
28: Compress function interrupted
The interrupted block is pushed completely (if possible) during runup
0000: Block completely pushed
0100: Interrupted block could not be completely pushed (s. F0002)
where F0001 = 0100:
nntt: Block number and block type
nn: Block number (hexadecimal)
tt: Block type (hexadecimal)
01 = DB, 02 = SB, 04 = PB, 05 = FX, 08 = FB, 0C = DX,
10 = OB ++)
29 F0000
F0001
29: MD8/9/10: Impermissible number of channels/spindles/axes
01: MD8: Too many channels
02: MD9: Too many spindles
03: MD10: Too many axes
33 F0000
F0001
F0002
F0003
33: MD error in DMP assignment lists or error in the DMP configuration
DB/DX
00: Error in DMP assignment lists (overlapping)
04: I/O type identifier: DMP I/O device configuration does not correspond
to configuration DB/DX
Otherwise: Error in the configuration lists DB/DX
Number of the DB/DX from MD 136 (BCD format)
When F0001=4: 0I or 0Q identifier input/output
Otherwise: Number of the incorrect/missing data word within the
configuration DB/DX (BCD format)
When F0001=4: Byte number (BCD format)
Otherwise: Unassigned ++)
34 F0000
F0001
F0002
F0003
F0004
34: Interface DMP/interface PLC not started correctly or EU incorrectly
jumpered
00: Interface DMP/interface PLC not started correclty (system startup)
01: Identifier for incorrect EU jumpering
Number of the interface module (at F0001=01)
Submodule number (when F0001=01)
Line number (when F0001=01) ++)
37 F0000
F0001
F0002
F0003
37: Distributed interrupt byte not available
Byte number (BCD format)
––
–– ++)
2 Diagnostics on the PLC
2.2 Additional error information (ACCU 3 low byte, DB 1 DW 161–163)
