Table 1-5: VMC 8030 Specifications
8030 SPECIFICATIONS 8030 STANDARD 8030 METRIC
Table Size 82.5" x 30" 2,096 mm x 762 mm
Floor to Table 36" 914 mm
T-Slots (No. x Width x Span) 5 x .708" x 5.512" 5 x 18 mm x 140 mm
Cutting Feed Rate .01-250 ipm (3765 @ 150%) .25-6,350 (9,525 at 150% )mm/min.
Rapid Feed Rate (X/Y/Z) 400 ipm (X/Y/Z) 10.1 m/min (X,Y,Z)
Max. Weight on Table 3,751 lbs. 1,701 kg.
Axis Drive Motor (X/Y/Z) AC, 5,000 lbs peak thrust AC, 22,420 N* thrust
Ball Screw Size 1.75" Dia. (X/Y) 1.50" Dia. (Z) 44.45 mm Dia (X,Y) 38.1 mm Dia. (Z)
Longitudinal (X Axis) 80" 2,032 mm
Cross (Y Axis) 30" 762 mm
Vertical (Z Axis) 30" 76 2mm
Spindle Nose to Table 5.5"-35.5" 140 mm-902 mm
Spindle Center to Column Ways 16" 406 mm
Main Motor - Automatic 2 Speed Vector 15 HP*, 11.2 KW
Opt. HT Motor - Automatic 2 Speed Vector 22.5 HP*, 16.8 KW
Opt. VHT Motor-Automatic 2 Speed Vector 30 HP*, 22.4 KW
Torque 160 ft-lbs, 220 ft-lbs (Opt.) 300 Nm/375 Nm
Accuracy, Axis Positioning ± .0004" .0076 mm
Accuracy, Axis Repeatability ± .0002" .0038 mm
Glass Scales (X/Y/Z) Optional
Spindle Speed 10-10,000 rpm (15,000 Opt.)
Spindle Orientation Electromechanical
Spindle Taper No. 40
ATC, Number of Tools 21 (30 Opt.)
ATC, Tool Selection Random, Bi-directional
Max. Tool Diameter 6" 152 mm
Max. Tool Length 15" 381
Max. Tool Weight 15 lbs. 6.8 kg
Machine Width and Depth 208" W x 93" D (w/o chip conveyor and 21”
wall clearance)
5292.9 mm W x 2352.3 mm D (w/o
chip conveyor and 21” wall clearance)
Machine Maximum Height 141" 3481.4 mm
Machine Weight 18,300 lbs. (w/o chip conveyor) 8300.7 kg (w/o chip conveyor)
Air Pressure Reqs. (Momentary) 120 psi, 15 scfm 5.5 Bar
Power Reqs. (3-phase) 30 amps 480VAC, 40amps, 480VAC, 70amps
480VAC
Cool Power System Spindle, Headstock, Ballscrew (Y)
Ball Screw Supports (X/Y/Z) dual
No. of Ground Boxways per Axis (X/Y/Z) 2
