FADAL MACHINING CENTERS
18 SPECIFICATIONS MAN-0126_R1
1.2 FADAL BOLT
TORQUE
SPECIFICATIONS
Table 1-9: Fadal Bolt Torque Specifications
COMPONENT MODEL LOCATION BOLT SIZE TORQUE UNIT
COLUMN ALL COLUMN TO BASE 5/8"-11 X X.50 HHB 175 FT-LBS
COLUMN ALL COUPLER SET SCREW 1/4"-20 X 0.50 SHSS 70 IN-LBS
COLUMN ALL Z B/S MOUNT IN BACK 3/8"-16 X X.XX HHB 45 FT-LBS
COLUMN ALL Z B/S MOUNT IN FRONT 1/2"-13 X 2.XX HHB 75 FT-LBS
COLUMN ALL Z B/S NUT 5/16"-18 X 1.25 HHB 30 FT-LBS
COLUMN ALL Z MOTOR 3/8"-16 X 1.25 SHCS 40 FT-LBS
COLUMN ALL Z XT B/S BEARING MOUNT 5/16"-18 X 1.50 HHB 25 FT-LBS
COLUMN ALL Z XT B/S BEARING SUPPORT (60/8030) 3/8"-18 X X.XX HHB 40 FT-LBS
COLUMN ALL Z XT B/S SUPPORT ADAPTER 5/16"-18 X 1.50 SHCS 15 FT-LBS
HEAD ALL SPINDLE 3/8"-16 X 1.00 SHCS 45 FT-LBS
HEAD ALL SPINDLE RETAINING RING 3/8"-16 X 1.00 HHB 25 FT-LBS
HEAD 7.5K RPM DRAWBAR PISTON 1/4"-20 X 2.00 HHB 15 FT-LBS
HEAD 7.5K RPM ORIENTATION BRIDGE (7.5K) 3/8"-16 X 6.00 SHCS 45 FT-LBS
HEAD 10K RPM BACK BELT GUIDE 1/2"-13 X 4.00 HHB 70 FT-LBS
HEAD 10K RPM HYDRAULIC PISTON 1/4"-20 X 2.00 HHB 15 FT-LBS
HEAD 10K RPM ORIENTATION BRIDGE (10K) 5/16"-18 X 6.00 HHB 30 FT-LBS
HEAD 10K RPM SPINDLE MOTOR 1/2"-13 X X.XX HHB 65 FT-LBS
HEAD 10K RPM SPINDLE MOTOR MOUNT 1/2"-13 X X.XX SHCS 70 FT-LBS
HEAD 10K RPM VIBRATION MOUNTS 1/2"-13 X 0.75 SHCS 70 FT-LBS
HEAD 10K RPM Z STRAP 3/8"-16 X 1.75 HHB 45 FT-LBS
X-Y AXIS ALL SADDLE STRAP 3/8"-16 X 1.75 HHB 45 FT-LBS
X-Y AXIS ALL TABLE STRAP 3/8"-16 X 0.75 HHB 45 FT-LBS
X-Y AXIS ALL X B/S NUT 5/16"-18 X 1.XX HHB 25 FT-LBS
X-Y AXIS ALL X-Y MOTOR 3/8"-16 X 1.XX SHSC 40 FT-LBS
X-Y AXIS ALL Y B/S NUT 5/16"-18 X 1.XX SHCS 30 FT-LBS
X-Y AXIS 60/8030 TABLE B/S BLOCK MOUNT (60/8030) 3/8"-16 X 3.50 SHCS 40 FT-LBS
X-Y AXIS 60/8030 X B/S SUPPORT MOUNT (60/8030) 1/2"-13 X 4.50 HHB 80 FT-LBS
X-Y AXIS 60/8030 X MOTOR MOUNT (60/8030) 1/2"-13 X 3.50 HHB 80 FT-LBS
X-Y AXIS 60/8030 Y MOTOR MOUNT (60/8030) 3/8"-16 X 1.50 HHB 40 FT-LBS
X-Y AXIS 22/30/4020 TABLE B/S BLOCK MOUNT (22/3016) 5/16"-18 X 2.75 SHCS 25 FT-LBS
X-Y AXIS 22/30/4020 X B/S SUPPORT MOUNT (22/30/4020) 3/8"-16 X 1.75 HHB 40 FT-LBS
X-Y AXIS 22/30/4020 X-Y MOTOR MOUNT (22/30/4020) 1/2"-13 X 3.XX HHB 80 FT-LBS
