FADAL MACHINING CENTERS
32 PRE-INSTALLATION PROCEDURES MAN-0126_R1
2.2 SHIPPING
DIMENSIONS
NOTE
All VMCs 6535 and 8030 do not get crated. (Unless specified by customer or distributor.) They are
placed on pallets and vacuum sealed.
Table 2-2: VMC Shipping Dimensions
VMC LENGTH WIDTH HEIGHT WEIGHT Z MTR DWN
8030 17ft 8in 8ft 8in 10ft 2in 19,000lbs 8ft 8in
6535 14ft 9in 8ft 10in 11ft 3in 30,000lbs 11ft 3in
6030 13ft 2in 8ft 8in 10ft 2in 17,000lbs 8ft 8in
4525 8ft 10in 7ft 10in 10ft 13,600lbs 8ft 5in
4020 9ft 7in 7ft 8ft 3in 10,500lbs 6ft 8in
4020 9ft 7in 7ft 9ft 1in ext col-
umn
10,500lbs 7ft 5in
3020 8ft 10in 6ft 10in 10ft 12,400lbs 8ft 5in
3016 8ft 3in 6ft 5in 8ft 2in 9,500lbs 6ft 8in
3016 8ft 3in 6ft 5in 8ft 8in ext col-
umn
9,500lbs 7ft 4in
2216 8ft 3in 6ft 5in 8ft 2in 9,100lbs 6ft 8in
2216 8ft 3in 6ft 5in 8ft 8in ext col-
umn
9,100lbs 7ft 4in
HYDRO 8ft 5in 4ft 2in 5ft 3in 820lbs
PALLET 7ft 2in 3ft 3in 3ft 8in 911lbs
Table 2-3: VMC Crated Dimensions & Weights
VMC LENGTH WIDTH HEIGHT WEIGHT
8030 17ft 8in 8ft 8in 10ft 2in 20,500lbs est
6535 20ft 10ft 4in 14ft 4in 35,000lbs est
6030 14ft 8ft 8in 10ft 2in 18,500lbs est
4525 10ft 5in 8ft 8ft 7in 16,000lbs est
4020 10ft 5in 8ft 8ft 7in 11,800lbs est
3020 9ft 8ft 8ft 7in 13,000lbs est
3016 9ft 7ft 8ft 7in 10,300lbs est
2216 9ft 7ft 8ft 7in 10,300lbs est
HYDRO 9ft 3in 4ft 9in 6ft 1,420lbs est
PALLET 7ft 9in 4ft 9in 6ft 1,411lbs est
