OCTOBER 2005 INSTALLATION PROCEDURE 59
SIEMENS
MAINTENANCE MANUAL
3.8 PENDANT
INSTALLATION
In order to install pendant, follow the next procedure:
VMC 6535
1. Carefully remove shipping crate, with pendant inside, from machine and place it
close to the right side of the machine.
2. Remove second (smaller) box from the machine.
3. Find the lower pivot pendant support and mount it on an appropriate position.
4. Carefully remove pendant from crate, place it on the mounted lower pivot pendant
support, and hold it.
5. Mount the upper pivot support while holding the pendant.
6. Mount pendant to both (upper and lower) pivot supports using screws and nuts
from the small box.
7. Open back panel of the pendant housing.
8. Pull all the cables coming from the machine through the upper pivot support and
the hole on the right top side of the pendant housing.
9. Connect these cables to appropriate positions according wiring diagram.
10. Connect remote bulk-head connector.
VMCs 2216, 3016, 6030, 8030
1. Carefully remove shipping crate, with pendant inside, from machine and place it
close to the right side of the machine.
2. Pull out cables and wires from the pendant support arm attachment point.
3. Mount the pendant support arm to this attachment point using screws and nuts
from the plastic bag.
4. Connect all the cables located at the junction in the support arm attachment point.
5. Mount support arm caps back to appropriate positions using screws from the
plastic bag.
