FADAL MACHINING CENTERS
42 INSTALLATION PROCEDURE MAN-0126_R1
3.1 MACHINE
INSTALLATION &
HOOK-UP
3.1.1 UNPACKING
Tools Required
Hammer, 15/16” socket or wrench and knife
1. Remove the crate and/or protective material from around the VMC.
2. Remove the strapping material from the front doors.
3. Unload the boxes from the inside and/or around the VMC.
4. Remove each of the four 5/8” bolts and nuts between the base of the VMC and the
pallet.
3.1.2 PLACING THE
VMC
1. Place the leveling pads (countersink side up) under the leveling bolts. Be sure
leveling bolts go into countersink on leveling pads.
NOTE
Use leveling pad SHp-0002 (PLC-0063 for slant sheet metal machines, or machines equipped with
the HydroSweep option) for placing the machine. Any other pad may cause damage to the machine.
2. Remove the fork lift bars or the eye bolts and the steel bar from the column.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
