1.2.6 6535 TABLE
Figure 1-14: 6535 Table
A
B
C
D
E
E
E
E
D
Table 1-15: 6535 Table Dimensions
VMC 6535
A 35.00” (889 mm)
B 74.76” (1899 mm)
C 69.50” (1765 mm)
D 2.74” (70 mm)
E 4.92” (125 mm)
