FADAL MACHINING CENTERS
58 INSTALLATION PROCEDURE MAN-0126_R1
Figure 3-12: Motors
Table 3-1: Couplers
MACHINE X AXIS Y AXIS Z AXIS
2216 KTR ROTEX GS24
.625x24mm
KTR ROTEX GS24
.625x24mm
KTR ROTEX AI GS24
.625x19mm
3016
3020
4020
4525
6030
8030
Table 3-2: Couplers
MACHINE X AXIS Y AXIS Z AXIS
6535/40T KTR ROTEX GS 28
.875x32mm
KTR ROTEX GS 28
.875x32mm
KTR ROTEX GS 28
.875x32mm
6535/50T
Z-AXIS 19ft
X-AXIS 8ft
Y-AXIS 8ft
