OCTOBER 2005 SPECIFICATIONS 17
SIEMENS
MAINTENANCE MANUAL
*Rated Peak Value
Table 1-8: VMC 6535 Specifications
6535 SPECIFICATIONS 6535 STANDARD 6535 METRIC
Table Size 74.8" x 26.5" 1,899mm x 673.1mm
Floor to Table 40.3" 1024mm
T-Slots (No. x Width x Span) 5 x .708" x 4.92" 5 x 18mm x 125mm
Cutting Feed Rate .01-400 ipm (600 ipm @ 150%) .25-10,160 (15,240 at 150%)
Rapid Feed Rate (X/Y/Z) 900 ipm (X/Y) 700 ipm (Z) 30.5(X,Y) 17.8(Z) m/min
Max. Weight on Table 4,250 lbs. 1,928 kg.
Axis Drive Motor (X/Y/Z) AC 3,800 lbs peak thrust AC, 16,903 N*thrust.
Ball Screw Size 62.2mm Dia. (X/Y/Z)
Longitudinal (X Axis) 65" 1,651mm
Cross (Y Axis) 35" 889mm
Vertical (Z Axis) 34" 864mm
Spindle Nose to Table 5"-39" 127mm-991mm
Spindle Center to Column Ways 37.4" 950mm
Opt. HT Motor - Automatic 2 Speed Vector 22.5 HP*, 16.8 KW
Opt. VHT Motor - Automatic 2 Speed Vector 30 HP*, 22.4 KW
Torque 220 ft-lbs, 270 ft-lbs (Opt.) 300 Nm/375Nm
Accuracy, Axis Positioning ± .00016" ±.004mm
Accuracy, Axis Repeatability ± .00006" ±.0015mm
Glass Scales (X/Y/Z) Optional
Spindle Speed 10-10,000 rpm (15,000 Opt.),(7,500, 50 tpr.Opt.)
Spindle Orientation Electromechanical
Spindle Taper No. 40 (50 Opt.)
ATC, Number of Tools 1.9 sec dual arm / 24, 62 tools (32, 40 50,tpr. Opt.)
ATC, Tool Selection Random, Bi-directional
Max. Tool Diameter Ø9.85” Ø250mm
Max. Tool Length 15.75" 400mm
Max. Tool Weight 40 lbs. 18 kg
Machine Width and Depth 219" W x130" D 5.56m W x 3.3m D
Machine Maximum Height 133" 3.4m
Machine Weight 29,000 lbs. 6,169 kg
Air Pressure Reqs. (Momentary) 120 psi, 15 scfm 5.5 Bar
Power Reqs. (3-phase) 30 amps 480VAC, 40amps, 480VAC, 70amps 480VAC
Power Reqs. (3-phase) 50 taper 70 amps, 480 VAC
Cool Power System Spindle, Ballscrews
Ball Screw Supports (X/Y/Z) dual
No. of Ground Boxways per Axis (X/Y/Z) 2
