OCTOBER 2005 SPECIFICATIONS 3
SIEMENS
MAINTENANCE MANUAL
*Rated Peak Value
Table 1-1: VMC 2216 Specifications
2216 SPECIFICATIONS 2216 STANDARD 2216 METRIC
Table Size 39" x 16" 750 mm x 406 mm
Floor to Table 31" 787 mm
T-Slots (No. x Width x Span) 3 x .708" x 4.33" 3 x 18 mm x 110 mm
Cutting Feed Rate .01-400 ipm (600 @ 150%) .25-10,160 (15,240 at 150%) mm/min.
Rapid Feed Rate (X/Y/Z) 900 ipm (X/Y) 700 ipm (Z) 22.8 m/min. (X,Y) 17.7 m/min (Z)
Max. Weight on Table 2,006 lbs. 991 kg.
Axis Drive Motor (X/Y/Z)* AC, 3,800 lbs AC, 16.900 N* thrust
Ball Screw Size 40mm Dia. (X/Y/Z)
Longitudinal (X Axis) 22" 559 mm
Cross (Y Axis) 16" 406 mm
Vertical (Z Axis) 20" (28" Opt.) 508 mm (711 mm Opt.)
Spindle Nose to Table 4"-24" (4"-32" Opt.) 102 mm-610 mm (102 mm-813 mm)
Spindle Center to Column Ways 16" 406 mm
Main Motor - Automatic 2 Speed Vector 15 HP*, 11.2 KW
Opt. HT Motor - Automatic 2 Speed Vector 22.5 HP*, 16.8 KW
Torque 160 ft-lbs, 220 ft-lbs (HT) 220 Nm/300 Nm
Accuracy, Axis Positioning ± .0002" .0050 mm
Accuracy, Axis Repeatability ± .0001" .0025 mm
Glass Scales (X/Y/Z) Optional
Spindle Speed 10-10,000 rpm (15,000 Opt.)
Spindle Orientation Electromechanical
Spindle Taper No. 40
ATC, Number of Tools 21,(opt 20, 1.9 sec. dual arm)
ATC, Tool Selection Random, Bi-directional
Max. Tool Diameter 3" (4.5" w/o adjacent tools) 76mm (114 mm w/o adjacent tools)
Max. Tool Length 15" 381
Max. Tool Weight 15 lbs. 6.8 kg
Machine Width and Depth 98" W x 67" D (w/o chip conveyor
or 21” wall clearance)
2481.6 mm W x 1700.4 mm D (w/o chip
conveyor or 21” wall clearance)
Machine Maximum Height 113" 2870.2 mm
Machine Weight 8,600 lbs. (w/o chip conveyor) 3900.9 kg (w/o chip conveyor)
Air Pressure Reqs. (Momentary) 120 psi, 15 scfm 5.5 Bar
Power Reqs. (3-phase) 30amp 480 VAC, 40 amps 480VAC
Cool Power System Spindle, Headstock, Ballscrews
Ball Screw Supports (X/Y/Z) X-dual, Y-single, Z 20”-single
No. of Ground Boxways per Axis (X/Y/Z) 2
