Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
124
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
Table 11- 14 OXYMAT 7: Gas inlet conditions
Gas inlet conditions
Sample gas pressure
Standard devices with hoses
500 to 1 500 hPa (absolute)
Tolerance within the valid pressure
range
± 150 hPa
Standard devices with hoses with
external reference gas pump
700 to 1 200 hPa (absolute)
Tolerance within the valid pressure
range
± 150 hPa
Standard devices with pipes
500 to 3 000 hPa (absolute); short-term < 5000 hPa (abs.)
Tolerance within the valid pressure
range
± 150 hPa
Reference gas pressure
High-pressure connection 2 000 hPa above sample gas pressure
(within permitted reference gas pressure range
2500 to 5000 hPa, abs.)
Low-pressure version with external
reference gas pump
Without vibration compensation
100 hPa above sample gas pressure
With vibration compensation
150 hPa above sample gas pressure
Pressure loss between sample gas
inlet and sample gas outlet
< 100 hPa at 1 l/min
Sample gas flow 18 to 60 l/h (0.3 to 1 l/min)
Sample gas temperature and humidity
OXYMAT 7 standard version 0 to 60 °C with relative humidity < 90%, avoid condensation
in the gas path (moisture content results in measurement
errors)
OXYMAT 7 high-temperature 0 ... 130 °C with relative humidity < 90%, avoid condensa-
tion in the gas path (moisture content results in measure-
ment errors)
Table 11- 15 OXYMAT 7: Temperature of sample chamber and gas path
Temperature of sample
chamber and gas path
OXYMAT 7
OXYMAT 7 high-temperature
Gas path
5 K above ambient temperature
72 ... 130 °C, adjustable
Sample chamber
72 °C
72 ... 130 °C, adjustable
