Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
125
Table 11- 16 OXYMAT 7: Time response
Time response
Warm-up period at room temperature
< 2 h
Response charac-
teristics
Delayed display T
90
with an electronic damping setting of 0 s
and a sample gas flow of 1 Nl/min - analyzer module in rack
or wall-mounted device
≤ 1.6 s
Dead time T
10
Analyzer module in rack-mounted device or wall-mounted
device
≤ 0.8 s
Table 11- 17 OXYMAT 7: Measuring response
Measuring response
Output signal variation with static damping
constant of 0 s and dynamic noise suppres-
sion of 5% / 10 s
≤ ±0.5% of smallest measuring span
(noise bandwidth corresponds to 1% = 6σ value or
0.333% = 2σ value),
with vibration compensation activated:
< 1.5 times value
Detection limit ≤ 1% of smallest measuring span according to name-
plate (with vibration compensation activated:
< 1.5 times value)
Measured value drift
At the zero point ≤ ±0.5% of the smallest measuring span/month or
≤ ± 50 vpm O
2
/month;
Whichever is greater
For span gas ≤ ±0.5% of the current measuring span/month or
≤ ± 50 vpm O
2
/month;
whichever is greater
Repeatability
At the zero point ≤ ±0.5% of the smallest measuring span/month or
≤ ± 50 vpm O
2
;
whichever is greater
For span gas ≤ ±0.5% of the current measuring span/month or
≤ ± 50 vpm O
2
;
whichever is greater
Linearity deviation with dry ambient air*
< 0.1%
* Untreated ambient air contains
less than 20.95% O
2
(literature value) since existing humidity of the
oxygen content is decreased relatively.
Table 11- 18 OXYMAT 7: Influence variables
Influence variables
Ambient temperature
Deviation at zero point ≤ 0.5% of the smallest measuring span/10 K or
≤ 50 vpm O
2
/10 K;
whichever is greater
